PANELS GATES & ACCESSORIES





                FIXED FIELD GATES


                Fixed, meshed or non-meshed field gates



                Standard fixed field gate
                                                          Measurement A in mm


                    432
                                                                                                            Spacing:  945 mm  1140 mm





                    708

                                 Spacing: 276 mm


                Semi-meshed field gate

                                                          Measurement A in mm


                    432
                                                                                                            Spacing:  945 mm  1140 mm




                    708







                Fully meshed field gate
                                                          Measurement A in mm


               432


                                      NOUVEAU !                                                                  Spacing:  945 mm  1140 mm

               708


















                        Upper fixture    Ø22 Eyelet rod and    Curved end   Meshed in the axis  Standard lock with
                         flat bar     welded reinforcement ring  brace Ø34                       non-return
