PANELS GATES & ACCESSORIES





               CLAMPS


               for locking yokes, gates, self-service feeders, etc.


                                                    92

                                                  33                    Adjustable clamps for

                                           30  <  <                     bare round Ø102 posts


                          867012              867004                      Ref   Name                         Packaging
                                                                         867012  Ø102 clamp - bare             20
                          184                          92               867004 Ø102 clamp - single             20

                   33             33                33          90 °     867019 Ø102 clamp - single in the axis  20
                                                                         867024 Ø102 clamp - double in the axis
                                                                                                               20
           30   <                            30  <                       867010 Ø102 clamp - double            20
                                                                        867005 Ø102 clamp - double corner      20
                                                <
                <
                                                                        867006 Ø102 clamp - triple             20
                     867010                   867005
                                                                         867007 Ø102 clamp - quadruple         20
                           184                                          867002 Ø102 clamp - single lock support in the shaft  20
                                                                        867003 Ø102 clamp - double lock support in the shaft  20
                    33              33
                                                                        860590 Ø102 clamp - single auto-block housing  20
                <
                                                                         860591 Ø102 clamp - double auto-block housing  20
                                                                        860434 Auto-block housing for locks in the shaft  20
             30 <
               867006                         867007





                   92


                           33
                   <
               30                                                                   81
                                                                  86
                    <
                         867019                867024                   867002                       867003


                                             29
                                                      Ø12
                    A simple push releases the
                          lock

                                      35
                                                        174  204



                                              115


                                 Closure position  860434              860590                       8605191

                           Opening position
