CUBICLES
ACCESSORIES FOR ADJUSTABLE CUBICLES
Assembly on square or round posts for height and width adjustment
Square tube supporting structure Square
SPECIFICATIONS 80/60
• Square size 80 post with plastic cap
• Caution: maximum two side walls between two posts
Ref Name
863008 Square size 80 embedded post, length 1.50 m
863021 Plate-mounted size 80 square post, length 1.20 m
Single-sided square structure
863704 Square size 80 embedded post, length 1.75 m
863720 Plate-mounted size 80 square post, length 1.45 m
860048 Zinc plated 12/110 anchor pin Box of 50
Ref Name
867517 Single square clamp 60/Ø60 allow for 2 per side wall, each
867518 Double square clamp 80/Ø60 2 for 2 side walls facing each other, each
863010 Hammered front size 60 square beam (2/cubicle) (6 m bar)
CUBICLES
863605 Individual square size 90 and size 70 cross pieces (2/post)
Recommendations for use
Post Height Madison Germania Euronorme Qualitagri
Double-sided square Embedded 1.50 m
structure
Plate-mounted 1.20 m
Embedded 1.75 m
Plate-mounted 1.45 m
Round tube supporting structure
Single-sided round structure Diam.
SPECIFICATIONS 76/60
• Ø 76 round post with welded cap
• Caution: maximum two side walls between two posts
Ref Name
863027 Diameter 76 embedded post, length 1.70 m
860065 Plate-mounted diameter 76 post, length 1.45 m
860048 Zinc plated 12/110 anchor pin Box of 50
Ref Name
867513 Single Ø 60 clamp, 2 per side wall, each
867514 Double Ø 60 clamp, 2 for 2 side walls facing each other, each
863706 Hammered Ø 60 tube (6 m bar)
863076 Solid Ø 76 x 60 mm clamp (for cross pieces), 2 per post
Recommendations for use
Post Height Madison Germania Euronorme Qualitagri
Embedded 1.75 m
Double-sided round Plate-mounted 1.45 m
structure
