CUBICLES







                                                             On square posts                        Square
                                                             Plate-mounted or embedded                80


                                                                 Ref   Name

                                                               863008  Square size 80 embedded post, length 1.50 m
                                                               863021  Plate-mounted size 80 square post, length 1.20 m
                                                               863704  Square size 80 embedded post, length 1.75 m
                                                               863720  Plate-mounted size 80 square post, length 1.45 m
                                                               860048  Zinc plated 12/110 anchor pin  Box of 50





                                                                 Ref   Name
                                                               867515  Single square 80/Ø60 clamp allow for 2 per post, each
                                                               867516  Double square 80/Ø60 clamp allow for 2 per post, each




                                                             On round posts                         Diam.

                                                             Plate-mounted or embedded                76             CUBICLES


                                                                 Ref   Name

                                                               863027  Diameter 76 embedded post, length 1.70 m
                                                               860065  Plate-mounted diameter 76 post, length 1.45 m
                                                               860048  Zinc plated 12/110 anchor pin  Box of 50





                                                                 Ref   Name
                                                               867511  Single clamp 76 x 60 allow for 2 per post, each
                                                               867512  Double clamp 76 x 60 allow for 2 per post, each






                                                                Ref    Name
                                                              863020   60/49 solid flange clamp
                                                              863005   60/49 single clamp
               Single U-clamp   60/49    Tapered               863712  Diameter 49 tube for head rails, length 6 m, hammered
                 60/49     solid flange
                             clamp




         Hot dip galvanisation provides long term surface corrosion protection. However, prolonged contact with silage, slurry/manure,
         ground treatments (drying, lime) and certain pellets can cause corrosion. We recommend protecting parts in contact with aggressive
         environments with regularly renewed protective paint .    See page 41
