PANELS GATES & ACCESSORIES

L.V.3 MODELS

Three tube adjustable length model

L.V.3. panels

Ref Name Packaging
Spacing: 945 mm 860137 Complete L.V.3. panel - 2/3 m 1 brace 15
Spacing: 545 mm 860136 Complete L.V.3. panel - 1/2 m 1 brace 15

860138 Complete L.V.3. panel - 3/4 m 1 brace 15
860139 Complete L.V.3. panel - 4/5 m 2 braces 15

860140 Complete L.V.3. panel - 5/6 m 2 braces 15
L.V.3. panel
860141 Complete L.V.3. panel - 6/7 m 3 braces 15

L.V.3 gates with a lock in the
Ø28 solid steel lock 2
positions manual shaft Ø28, anti return

Spacing: 945 mm 861516 Complete L.V.3. gate - 1/2 m 1 brace 15
Spacing: 545 mm Ref Name Packaging

861517
Complete L.V.3. gate - 2/3 m 1 brace
15
861518 Complete L.V.3. gate - 3/4 m 1 brace 15
861519 Complete L.V.3. gate - 4/5 m 2 braces 15
L.V.3. gate
861520 Complete L.V.3. gate - 5/6 m 2 braces 15
861521 Complete L.V.3. gate - 6/7 m 3 braces 15

Measurement A in mm

496 Spacing: 545 mm Individual panels

Ref
706 mm 860017 Name Measurement A
L.V.3. back - 1 m (1/2), 1 brace
1090
860018 L.V.3. back - 1.50 m (2/3), 1 brace 1590
L.V.3. gate front Ref. 861514
860019 L.V.3. back - 2.50 m (3/4), 1 brace 2590
Measurement A in mm
Measurement A in mm
860020 L.V.3. back - 3.50 m (4/5), 2 braces 3590
Spacing: 945 mm Spacing: 545 mm Spacing: 945 mm 860022 L.V.3. back - 4.50 m (5/6), 2 braces 5850
Spacing: 545 mm
4610
860021
L.V.3. back - 5.74 m (6/7), 3 braces
861514
860149 Standard L.V.3. gate front (1.70 m) 1630
Standard L.V.3. panel front (1.70 m)
1690
L.V.3. panel front Ref. 860149
L.V.3. back

24 - CATALOGUE N°33
