CATTLE LOCKING YOKES & SELF SERVICE FEEDERS





                CATTLE LOCKING YOKE ACCESSORIES


                Suitable for cattle locking yokes


                         Ref. 861039  Ø16.5       Ref. 861034  Ø14
                                                                Cattle locking yoke stands


                    295 mm                    295 mm        100 mm                       Ref  Name
                    336 mm                    302 mm
                                                                                       861039  Offset stand
                         Ref. 861032         Ref. 861033                Ref. 861136  Ø16.5  861034  Plate-mounted stand
                               Ø14                                   40 mm
                    100 mm                                 Ø16                         861032  Ecofix stand
                                                                                       861033
                                                                                              Adjustable Collar Panel (P.E.R.) bracket
                          495 mm              295 mm                 295 mm
                                              333 mm                                    861136  Bracket stand
                                                                Extended cattle locking yoke stands
                 Ref. 861922 A       Ref. 861923 B
                                                     Choose 2 stands +
                 1070 mm             1070 mm          1 bar ref. 861926        Ref    Name
                                                                             861922   Long offset stand          A
                Ref. 861924  C       Ref. 861925 D                           861923   Long plate-mounted stand   B
                                                                Ref. 861926  861924   Long P.E.R. stand          C

                 1070 mm              1070 mm                                861925   Long bracket stand         D
                                                                  E          861926   Diameter 49 bar + 2 49/49 coupling clamps  E

                                                                Workman access for cattle locking yokes
                       627 mm

                                  Swivelling
                                    plate                           Ref    Name
                                                                 990080 *  Workman access for cattle locking yoke with gate
                                                    397 mm       990050 *  Workman access for cattle locking yoke without gate
                                                                  990054   Individual gate for workman access
                                                            *   EACH REFERENCE MUST BE FOLLOWED BY A LETTER INDICATING THE REQUIRED LOWER STAND

             Ref. 990080                  Ref. 990050         ASSEMBLY. IF NOT INDICATED THE WORKMAN ACCESS WILL BE SHIPPED WITH STAND A.

                                                                                  * Option code
                                  Choose the lower
                                    stand type                     A             B            C             D
                     Ø76
                                                              L = 1070 mm   L = 1070 mm    L = 1070 mm   L = 1070 mm
                        100
                                   Ref. 860583                  Locking yoke accessories
                                   Ref. 860459
                                                Ref. 860588
                                                Ref. 860589        Ref    Name
                         945                                      861122  Locking yoke flat sloping bar
                                         Ref. 867622              867622  Ø76 post for locking yoke stiffener len 2m00
                                                                  861262
                                                                          Sheath for Ø76 post
                        2250                               Ref. 861065  868520  Rail coupling (Ø20 tube)


                   Ref. 861262  Ref. 860449  50  76  28  Ref. 861122  860449  100*100*4 post - 2m25 - drilled + 4 screws (for ecofix stand)
                                                                  861065
                                                                          Locking yoke central stiffener (clamp+tube Ø42)
                                                                  860583
                                                                          P.V.B. stiffener 80 X 80 beam - 100/150 mm
                                            600                   860459  P.V.B. stiffener 80 X 80 beam - 160/250 mm
                                                     Ø20          860588  Locking yoke stiffener Ø60 - 100/150 mm
                                       Ref. 868520
                                                                  860589  Locking yoke stiffener Ø60 - 160/250 mm
