CATTLE LOCKING YOKES & SELF SERVICE FEEDERS

P.V.B. ROBUST

Panels with locking at the bottom suitable for horned meat breeds

P.V.B. ROBUST cattle yoke with lower stiffener

SPECIFICATIONS
Panel Locking at the Base
(bracing at the base)

• Cattle yoke for horned animals with base locking
• Wear resistant bearing block on the hinge, lubrication possible

• Lower reinforcement using beam and braces (at each place)
square 80 x 80 mm

• Adjustable at ends using four 22 mm diameter eye rods

• Locking using a high strength polyamide ratchet
• Model manufactured using 80 mm square tubes and diameter

60 mm round tubes

• Fixture spacing: 70 cm

• Basement: 27 cm

• A reinforcement that must be anchored
860459 or 860583
Ref Name Min adjustment max adjustment
860459 P.V.B. stiffener 80x80 beam - 160/250 mm 160 250
860583 P.V.B. stiffener 80x80 beam - 100/150 mm 100 150
ADJUSTMENT 120407 Clamp 100x100 - Standard - 1D
120408
Clamp 100x100 - Standard - 2D
Clamps adaptable for P.V.B. assembly Robust panels

30
30

90 180
120407 Clamp 100x100 - Standard - 1d 120408 Clamp 100x100 - Standard - 2d
