CUBICLES

Cordoba cubicle for embedding

SPECIFICATIONS Diam.
60
• Cordoba embedded cubicle side wall
• Model manufactured using Ø 60 tube, length 2.05 m
• With no back leg

Ref Name
863630 Cordoba embedded side wall, length 2.05 m

863020 60/49 solid flange clamp

863005 60/49 single clamp
Single U-clamp 60/49 Tapered
60/49 solid flange 863712 Diameter 49 tube for head rails, length 6 m, hammered
clamp

Plate-mounted Cordoba cubicle

SPECIFICATIONS Diam.
60 CUBICLES

• Cordoba plate-mounted cubicle side wall
• Model manufactured using Ø 60 tube, length 2.05 m
• With no back leg

Ref Name

863635 Cordoba plate-mounted side wall, length 2.05 m
863020 60/49 solid flange clamp

863005 60/49 single clamp

Single U-clamp 60/49 Tapered 863712 Diameter 49 tube for head rails, length 6 m, hammered
60/49 solid flange
clamp

Plate-mounted Madison cubicle

SPECIFICATIONS Diam.
60
• Madison plate-mounted cubicle side wall

• Model manufactured using Ø 60 tube, length 2.05 m
• With no back leg

Ref Name

863645 Madison plate-mounted side wall, length 2.05 m
863020 60/49 solid flange clamp

863005 60/49 single clamp
Single U-clamp 60/49 Tapered 863712 Diameter 49 tube for head rails, length 6 m, hammered
60/49 solid flange
clamp
