CALF EQUIPMENT

PARTITIONS, SELF SERVICE FEEDERS AND M.B.O.

Opening calf partitions SPECIFICATIONS
278
Ø33.7
• Frame manufactured using Ø 42 tube and Ø 20 bars
(every 10 cm)
Adjustable
Ø42.4 stand • Partition opens in both directions
Ø20 • Supplied with 2 adjustable stands
105

Ref
Name
825 mm SPACING: 782 mm 862104 Opening partition, Length 2.5 m Tube cross section Min A MEASUREMENT Max A MEASUREMENT
2410
2410
2570
862105 Opening partition, Length 3 m
862106 Opening partition, Length 4 m 2860 2860 3020 CALF EQUIPMENT
4070
3910
3910
TUBE CROSS SECTION
862107 Opening partition, Length 5 m 4910 4910 5070
MEASUREMENT A
Calf self-service SPECIFICATIONS

• Made from Ø 60 tube for the back and
60x60 Ø60.3 Ø 49 for the variable front part
• 1.70 m long adjustable front part.
• Spacing between bars: 30 cm

426 303 410 Ref Name Min A MEASUREMENT Max A MEASUREMENT

860707 Calf self-service, length 1/2 m 1220 2040
860708 Calf self-service, length 2/3 m 1810 3140

860709 Calf self-service, length 3/4 m 2720 4140
MEASUREMENT A 860710 Calf self-service, length 4/5 m 3720 5140
860711 Calf self-service, length 5/6 m 4740 6160

Calf M.B.O. Ø42.4 Ø26.9
Collar SPECIFICATIONS
• Model manufactured using Ø 42 (frame) and
Ø 27 tubes (bends)
• Spacing between bars: 195 mm
780 • Adjustable bracket to adapt the length
• Same centre distance as 78 cm calf locking yoke.
• Central stiffener included on 4m and 5m elements
(must be embedded)
TUBE CROSS SECTION

MEASUREMENT B
Ref Name Tube cross section Min B MEASUREMENT Max B MEASUREMENT Collar
860054 Calf M.B.O., Length 3 m (11 places) 2800 2886 3166 195
860055 Calf M.B.O., Length 4 m (15 places) 3800 3886 4166 200
860056 Calf M.B.O., Length 5 m (20 places) 4800 4886 5166 195

860035 Offset bracket only for 42.4 mm diameter tube

- CATALOGUE N°33 49
